Fixing tie for hole (oval), ∅1.5-50.0mm, black, 1000pcs.
Art.-No. 156-03110 | T50RX2DUALSDFTOVAL-PA66HIRHSUV-BK | 세부

Pre-assembled 2-piece fixing tie with fir tree foot part
Cable tie head can be moved after bundling
Easy to assemble without the need for a tool
Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
Fir tree foot part can be used for a variety of panel thicknesses
Suitable for use within threaded holes
DOP versions for oval holes feature anti-twist protection

More products in this product group:

Application	Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
Cable Tie	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Colour	Black (BK)
Description	These two-piece fixings are supplied ready assembled and offer a simple and versatile method of bundling and fixing cables. The fir-tree base will easily push into pre-punched holes in panels or threaded, blind, holes and offers a very secure fixing. The two-piece design enables the head of the tie to be orientated to the required position to ease assembly, whilst the 'disc' on the top of the fir tree covers the hole and minimises the ingress of water and dirt.
Fixation Method	Fir Tree for oval holes
Identification Plate Position	none
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION	T50RX2DUALSDFTOVAL-PA66HIRHSUV-BK
Pack Content	1000pcs.
Package Content packed in	carton
Product Family	for oval holes
Product Group	2-piece fixing ties with fir tree, with disc
Tie Closure	plastic pawl
Type	T50RX2DUALSDFTOVAL

Bundle Diameter max (metric)	50.0mm
Bundle ∅ min.	1.5mm
Fixing Hole Shape	Oval
Height (H)	22.85mm
Height (H2)	12.85mm
Hole Depth	0.60mm
Hole Depth	6.75mm
Length (L)	203.2mm
Min.Tensile Strength	225N
Panel Thickness	0.02 - 0.26"
Panel Thickness max.	0.6 - 6.75mm
Panel Thickness max. (imperial)	0.26"
Panel Thickness min. (imperial)	0.02"
Width (W)	17.31mm
for Hole ∅ (FH)	6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
for Panel Thickness min - max	0.6 - 6.8 mm
for Panel Thickness min - max	0 - 0.3 "
