Fixing tie for hole (round), inside serrated, ∅10.0-100.0mm, black, 200pcs.
Art.-No. 156-01096
| X120RDHDM6-PA66HIRHS/PA66W-BK
|
세부
- Pre-assembled 2-piece fixing tie
- Cable tie head can be moved after bundling
- Secure alignment to the bundle due to H-design
- A suitable alternative for metal clamps
- Withstands vibrations and displacement forces
- High tightening torque through metal bushing
More products in this product group:
| Application | Used in the automotive and truck industry for harness fixing in the engine body, these parts offer solutions in many other industrial applications with difficult environment. |
| Colour | Black (BK) |
| Description | 2-Piece fixing tie 369*7.7 mm, pre-assembled, high impact modified, heat stabilised, black. The mount allows the parallel routing of cable ties and it is set thanks to M6 screw. |
| Fixation Method | Screw Mounting and Rivet |
| Identification Plate Position | none |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Polyamide 6.6, UV-resistant (PA66W) |
| Mounting Screw Type | M6 Screw |
| PART DESCRIPTION | X120RDHDM6-PA66HIRHS/PA66W-BK |
| Pack Content | 200pcs. |
| Package Content packed in | carton |
| Product Family | DHDM-Series for parallel routing |
| Product Group | 2-Piece Fixing Ties for Heavy Duty Applications, for Screws or Bolts |
| Tie Closure | plastic pawl |
| Type | X120RDHDM6 |
다운로드
|
|
|
| GTIN-13 / EAN | 4031026463414 |
| Packaging 1 - Height (m) | 0.1m |
| Packaging 1 - Length (m) | 0.26m |
| Packaging 1 - Qty | 50 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0104m³ |
| Packaging 1 - Weight (kg) | 0.848201kg |
| Packaging 1 - Width (m) | 0.4m |
| Packaging 3 - Height (m) | 0.25m |
| Packaging 3 - Length (m) | 0.6m |
| Packaging 3 - Qty | 200 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.06m³ |
| Packaging 3 - Weight (kg) | 4.142804kg |
| Packaging 3 - Width (m) | 0.4m |
| Packaging 4 - Height (m) | 1.144m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 3200 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.098m³ |
| Packaging 4 - Weight (kg) | 87.285kg |
| Packaging 4 - Width (m) | 0.8m |
