Bundling clip for hole (round), L=50.0mm, SO=20.0mm, black, 1000pcs.
Art.-No. 151-00830 | CH20FT6-PA66HIRHS-BK |  세부

Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION CH20FT6-PA66HIRHS-BK
Pack Content 1000pcs.
Package Content packed in bag
Product Family Round holes
Product Group Bundling Clips with Fir Tree for Distance Routing
Type CH20FT6
Bundling Bar Length 50.0mm
Length (L) 50.0mm
Length (L2) 20.0mm
Offset Length 20.0mm
Panel Thickness max. 0.8 - 2.5mm
for Hole ∅ (FH) 6.5 - 7.0 mm
for Panel Thickness min - max 0.8 - 2.5 mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026409757
Packaging 1 - Qty 1000
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 0.130001kg
Packaging 3 - Height (m) 0.22m
Packaging 3 - Length (m) 0.57m
Packaging 3 - Qty 6000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0495m³
Packaging 3 - Weight (kg) 1.6kg
Packaging 3 - Width (m) 0.395m
Packaging 4 - Height (m) 1.244m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.194m³
Packaging 4 - Weight (kg) 53.0kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121702
