19/11/2024

Corrugated tube clip for hole (round)/with pipe/tube holder, nom∅16.0mm, black, 2000pcs.
Art.-No. 151-02577 | CTC16FT8-PA66HS-BK |  세부

Application CTC clamps are used for example in the automotive, harness making, electrical industry and wherever corrugated tubing has to be quickly and firmly fixed.
Colour Black (BK)
Fixation Method Fir Tree
Key product features for convoluted tubes or with rib, removable, lockable
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION CTC16FT8-PA66HS-BK
Pack Content 2000pcs.
Package Content packed in carton
Product Family CTC-Series
Product Group Fixing elements for corrugated tubing, with fir tree
Type CTC16FT8
Attach to Ø 16.0
Bundle Diameter max (metric) 8.2mm
Bundle ∅ min. 7.8mm
Disc ∅ 16.0mm
Height (H) 47.8mm
Height (H2) 11.5mm
Length (L) 31.5mm
Nominal ∅ 16.0mm
Panel Thickness max. 0.6-5.5mm
Width (W) 14.0mm
for Hole ∅ (FH) 7.8 - 8.2 mm
for Panel Thickness min - max 0.6 - 5.5 mm
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026613802
UNSPSC Key 39121702
