17/07/2024

Label, white, dot-matrix print, 19.05mm, H2=38.1mm, 5000pcs.
Art.-No. 595-27400 | TAG27-400-WH |  Details

    • Ideal when requirement to print labels for use in harsh environments is needed
    • Highly conformable material ensures users are able to use the material for both asset marking and cable flagging
    • Withstands high temperatures, an aggressive chemical environment, and has long term survivability
    Add to watchlist
    Downloads Datasheet
    Application White Polyester Splice Enclosure Label
    Colour White (WH)
    Material Type 400, Polyester, white (400)
    PART DESCRIPTION TAG27-400-WH
    Pack Cont. 5000pcs.
    Package Content packed in pack
    Type TAG27
    Bundle ∅ 6.10mm
    Bundle ∅ min. 6.10mm
    H printable 19.00mm
    HR 50.80mm
    HR 2.0"
    Height (H2) 38.1mm
    Print Method dot-matrix print
    Thickness (T) 25.0µm
    VR 25.40mm
    VR 1.0"
    Width (W) 19.05mm
    Width of LIner (WL) 7.625"
    Width of Liner (WL) 193.70mm
    Adhesive Acrylic
    Adhesive Operating Temperature -40 °C to +150 °C
    CE Certification No
    CSA Certified No
    Curing Temperature from +10 °C
    Halogen-free No
    Operating Temperature -40 °C to +150 °C
    ROHS compliant Yes
    Specifications
    Specifications UL-Recognized
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) No
    UL-File Number MH18396
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026724379
    Labels per Column 1
    Labels per Row 1
    Packaging 1 - Weight (kg) 0.27kg
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
    UNSPSC Key 55121612
