Cable tie tool for 2.5-4.8mm, pneumatic, 0.87kg, black
Art.-No. 110-07100
| MK7P-PA66GF30-BK
|
Details
- Enhanced technology for better application of cable ties
- Improved compressed air supply for faster tensioning piston movement
- Shorter processing time and greater volume of connecting tie application
- Genuine potential for rationalisation
- Ergonomic design, moulded handle to prevent slippage, reduce operator fatigue
- Lightweight but very tough housing made of glass fibre-reinforced plastic
- Meets high industry standards
- Tensionioning and cutting off cable ties flush with head by pressing one button
- Smooth cut edge to prevent injuries
- Automatic ejection of cut-off cable tie end
- Three-level preset control to set tool tension
- Optional safety cap to prevent tension setting from being changed by accident
- (Important when bundling sensitive materials and maintaining process reliability)
- Non-slip, comfortable grip, soft touch trigger, and one-touch tensioning/cut off
- Very lightweight and easy to use on all cable ties 2.5 - 4.8 mm wide
Request your individual offer now
Request quote
More products in this product group:
| Application | The MK7P pneumatic bundling tool sets a new benchmark for the rational application of ties in the industrial production process. Improved compressed air supply moves the tensioning piston faster than in comparable tools. |
| Air Pressure (min.) | 3Bar |
| Air Pressure Psi (max.) | 90Psi |
| Air att. Position | lower air connection |
| Colour | Black (BK) |
| Description | MK7P |
| For Cable Tie Width | 2.5-4.8mm |
| Material | Polyamide 6.6, glass-fibre reinforced (PA66GF30) |
| Number of cycles | 1000000 |
| Operation | pneumatic |
| PART DESCRIPTION | MK7P-PA66GF30-BK |
| Pack Content | 1pc. |
| Package Content packed in | carton |
| Product Family | MK7P up to 4.8 mm strap width |
| Product Group | Pneumatic tensioning tool plastic housing |
| Strap Thickness max. | 1.5 |
| Tool property | Automatic cut off |
| Tool suitable cable tie material | Plastic |
| Type | MK7P |
| for Air Pressure min - max | 3 - 6 Bar |
Download
| Dimensions W x H x D | 40 mm x 170 mm x |
| GTIN-13 / EAN | 4031026218045 |
| Packaging 1 - Height (m) | 0.06m |
| Packaging 1 - Length (m) | 0.37m |
| Packaging 1 - Qty | 1 |
| Packaging 1 - Type | carton |
| Packaging 1 - Volume (m³) | 0.00666m³ |
| Packaging 1 - Weight (kg) | 1.37kg |
| Packaging 1 - Width (m) | 0.3m |
| Packaging 2 - Height (m) | 0.216m |
| Packaging 2 - Length (m) | 0.3048m |
| Packaging 2 - Volume (m³) | 0.0176m³ |
| Packaging 2 - Width (m) | 0.267m |
SP MK7P replacement blade-ST-BK
110-07111
MK7P
110-07101
SP MK7P replacement blade
110-07111
