23/12/2024

Cable tie mount, Wmax=12.7mm, black, 50pcs.
Art.-No. 151-02868 | CMT1-PA11W-BK |  Details

    • Could be used for plastic flexible conduits of diameter 16, 22 and 28
    • Can be easily fixed to the channel by turning 90 degrees. Screws and tools are not needed
    • Since the ribs prevent slippage, the plastic flexible conduit can be fixed firmly.
    • Made of PA11, which features are weather resistant, heat stabilized and chemical resistant.
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Use to fix plastic flexible conduit with cable ties
    Colour Black (BK)
    Material Polyamide 11, UV-resistant (PA11W)
    PART DESCRIPTION CMT1-PA11W-BK
    Pack Content 50pcs.
    Package Content packed in bag
    Product Family PA11
    Product Group Mount for metal channels
    Type CMT1
    Height (H) 17.8mm
    Length (L) 40mm
    Length (L2) 37mm
    Max. Tie Width (G) 12.7mm
    Width (W) 19mm
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4944387119350
    UNSPSC Key 39121717
    Self-Adhesive cable tie mounts Self-Adhesive cable tie mounts

    Self-Adhesive cable tie mounts

    HellermannTyton self-adhesive cable tie mounts are perfectly suited for cable fastening on round and angled surfaces. To save time, reduce part diversity and weight.
