19/12/2024

Cable tie mount for screw fixation, Wmax=5.0mm, ∅5.0 x 19.0 mm, #10 Screw, white, 500pcs.
Art.-No. 151-30203 | CTAP2-PA66-WH |  Details

Cable tie anchor mounts are installed quick and easy by securing a single screw.

    • Suitable for applications with minimal space
    • Mounted before cable installation and in line with cable
    • CTAP mounts offer adjustable stand off feature for precision placement
    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Each of these products offers particular benefits, but all are designed for simple, yet robust, installation in a wide variety of applications - particularly used in telecoms equipment, switchgear and control cabinets.
    Colour White (WH)
    Fixation Method Screw Mounting and Rivet
    For Ties T18 - T50
    Material Polyamide 6.6 (PA66)
    Mounting Screw Type #10 Screw
    PART DESCRIPTION CTAP2-PA66-WH
    Pack Content 500pcs.
    Package Content packed in bag
    Product Family CTAM-Series for applications where space is limited
    Product Group Screw fixing mounts
    Type CTAP2
    Height (H) 3.5mm
    Length (L) 54.1mm
    Max. Tie Width (G) 5.0mm
    Strap Width max. (G) 0.2"
    Width (W) 54.10mm
    for Hole ∅ (FH) 5.0 x 19.0 mm
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V2
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Specifications UL
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) Yes
    UL-File Number E64139
    GTIN-13 / EAN 4031026301600
    UNSPSC Key 39121717
