Fixing tie, inside serrated, ∅5.0-105.0mm, black, 500pcs.
Art.-No. 156-04007 | T120R2xDHVSDL12x17-PA66HIRHSUV-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Cable Tie Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T120R2xDHVSDL12x17-PA66HIRHSUV-BK
    Pack Content 500pcs.
    Package Content packed in carton
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T120R2xDHVSDL12x17
    Variant Inside Serrated
    Bundle Diameter max (metric) 105.0mm
    Bundle ∅ min. 5.0mm
    Height (H) 34.74mm
    Height (H2) 13.07mm
    Hole Depth 6.75mm
    Hole Depth 0.60mm
    Length (L) 203.2mm
    Min.Tensile Strength 535N
    Panel Thickness 0.02 - 0.26"
    Panel Thickness max. 0.6 - 6.75mm
    Panel Thickness max. (imperial) 0.26"
    Panel Thickness min. (imperial) 0.02"
    Thickness (T) 1.8mm
    Width (W) 7.6mm
    Width (W2) 1.26"
    Width (W2) 32.0mm
    for Hole ∅ (FH) 12.0 x 17.0 mm
    for Panel Thickness min - max 0 - 0.3 "
    for Panel Thickness min - max 0.6 - 6.8 mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026662961
    Packaging 3 - Height (m) 0.219m
    Packaging 3 - Length (m) 0.606m
    Packaging 3 - Qty 500
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0528m³
    Packaging 3 - Weight (kg) 4.45kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Qty 15000
    Packaging 4 - Type pallet
    UNSPSC Key 39121702
