Fixing tie for cable bundles, inside serrated, ∅10.0-105.0mm, grey, 250pcs.
Art.-No. 156-04004 | T120RCOUPLER-PA46-GY |  Details

    • Pre-assembled 2-piece fixing tie with coupler
    • Cable tie head can be moved after bundling
    • Easy addition of cables after assembly
    • For parallel routing of bundles that can be twisted 90° even after installation
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Grey (GY)
    Description The Coupler is the simple way to connect two cable ties for a parallel routing of two bundles. His special design allows the ties 90 degrees of rotation. This is ideal for all applications where the cable, pipe or hose should move flexible in relation to the fixing point. The Coupler can be used with one or two cable ties. This allows easily subsequent installation or replacements of further cables, pipes or hose.
    For Ties T120
    Identification Plate Position none
    Key product features for multiple routing
    Material Polyamide 4.6 (PA46)
    PART DESCRIPTION T120RCOUPLER-PA46-GY
    Pack Content 250pcs.
    Package Content packed in carton
    Product Family twistable up to 90°
    Product Group 2-piece fixing ties for parallel separation
    Tie Closure plastic pawl
    Type T120RCOUPLER
    Variant Inside Serrated
    Bundle Diameter max (metric) 105.0mm
    Bundle ∅ min. 10.0mm
    Height (H) 14.9mm
    Length (L) 390.0mm
    Max. Tie Width (G) 7.62mm
    Min.Tensile Strength 535N
    Strap Width max. (G) 0.3"
    Width (W) 7.6mm
    ∅ max. 1. loop 100.0mm
    ∅ max. 2. loops 100.0mm
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +130 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    GTIN-13 / EAN 4031026662350
    Packaging 3 - Type box
    UNSPSC Key 39121717
