Fixing tie for hole (oval), inside serrated, ∅5.0-105.0mm, black, 1000pcs.
Art.-No. 156-03370 | T120RSADFTOVALSET-PA66HIRHSUV-BK |  Details

Fir tree mounts are designed to provide low insertion force and high extraction force.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Cable Tie Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Colour Black (BK)
    Fixation Method Fir Tree for oval holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T120RSADFTOVALSET-PA66HIRHSUV-BK
    Pack Content 1000pcs.
    Package Content packed in carton
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T120RSADFTOVALSET
    Variant Inside Serrated
    Bundle Diameter max (metric) 105.0mm
    Bundle ∅ min. 5.0mm
    Disc ∅ 17.6 x 23.6mm
    Disc ∅ 0.69 x 0.93"
    Fixing Hole Shape Oval
    Height (H) 23.4mm
    Height (H2) 12.85mm
    Length (L) 385.0mm
    Min.Tensile Strength 535N
    Panel Thickness 0.02 - 0.26"
    Panel Thickness max. 0.6 - 6.75mm
    Panel Thickness max. (imperial) 0.26"
    Panel Thickness min. (imperial) 0.02"
    Thickness (T) 1.8mm
    Width (W) 7.6mm
    for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
    for Panel Thickness min - max 0 - 0.3 "
    for Panel Thickness min - max 0.6 - 6.8 mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026658988
    Packaging 3 - Height (m) 0.212725m
    Packaging 3 - Length (m) 0.51435m
    Packaging 3 - Qty 1000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0347m³
    Packaging 3 - Weight (kg) 7.7kg
    Packaging 3 - Width (m) 0.3175m
    Packaging 4 - Qty 40000
    Packaging 4 - Type pallet
    UNSPSC Key 39121703
