Cable tie outside serrated, 270.0x12.7mm, ∅70.0mm, black, 500pcs.
Art.-No. 111-01671
| TAS120M-PA66HIRHSUV-BK
|
Details
- Halogen-free
- Suitable for installation in public areas, road or railway tunnels
- Built-in spacer for easy and quick installation
More products in this product group:
| Application | Designed as a catenary mounting tie it is simple to use. Typical applications are for suspending cables between buildings, supporting antenna cables or installation of railway signalling cables. |
| Colour | Black (BK) |
| Fixation Method | Others |
| Identification Plate Position | none |
| Key product features | for direct fixation |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| PART DESCRIPTION | TAS120M-PA66HIRHSUV-BK |
| Pack Content | 500pcs. |
| Package Content packed in | bag |
| Product Family | For parallel routing of pipes and harnesses |
| Product Group | 1-piece fixing tie with built-in spacer |
| Releasable Closure (Yes/No) | No |
| Tie Closure | plastic pawl |
| Type | TAS120M |
| Variant | Outside Serrated |
Download
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | Yes |
|
|
|
| GTIN-13 / EAN | 4031026514598 |
| Packaging 1 - Height (m) | 0.022m |
| Packaging 1 - Length (m) | 0.317m |
| Packaging 1 - Qty | 1 |
| Packaging 1 - Type | pcs. |
| Packaging 1 - Volume (m³) | 0.00022m³ |
| Packaging 1 - Weight (kg) | 0.012kg |
| Packaging 1 - Width (m) | 0.032m |
| Packaging 3 - Height (m) | 0.37465m |
| Packaging 3 - Length (m) | 0.59055m |
| Packaging 3 - Qty | 500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0646m³ |
| Packaging 3 - Weight (kg) | 7.09kg |
| Packaging 3 - Width (m) | 0.29209999999999997m |
| Packaging 4 - Height (m) | 1.27m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 6000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.219m³ |
| Packaging 4 - Weight (kg) | 100.8kg |
| Packaging 4 - Width (m) | 0.8m |
