24/12/2024

Bundling clip for hole (round), L=51.0mm, SO=37.5mm, silver, 2500pcs.
Art.-No. 133-04335 | BCATC90DEG-PPS-SR |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Silver (SR)
    Fixation Method arrowhead
    Material Polyphenylene Sulfide (PPS)
    PART DESCRIPTION BCATC90DEG-PPS-SR
    Pack Content 2500pcs.
    Package Content packed in bag
    Type BCATC90DEG
    Bundling Bar Length 51.0mm
    Height (H) 51.0mm
    Length (L) 51.0mm
    Offset Length 37.5mm
    Panel Thickness 0.53 - 0.59"
    Panel Thickness max. 13.5 - 15.0mm
    Panel Thickness max. (imperial) 0.59"
    Panel Thickness min. (imperial) 0.53"
    Width (W) 16.0mm
    for Hole ∅ (FH) 11.7 - 13.0 mm
    for Panel Thickness min - max 13.5 - 15 mm
    CE Certification No
    CSA Certified No
    ROHS compliant No
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 4031026725628
    Packaging 3 - Height (m) 0.2159m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.052m³
    Packaging 3 - Weight (kg) 10.63kg
    Packaging 3 - Width (m) 0.396875m
    UNSPSC Key 39121702
