Connector clip for connector/for hole (oval), EWCAP-005-11, silver, 5000pcs.
Art.-No. 151-02896 | CC11B-PPS-SR |  Details

Oval fir tree ensures a tight connection without rotation.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Silver (SR)
    Fixation Method Fir Tree for oval holes
    Material Polyphenylene Sulfide (PPS)
    PART DESCRIPTION CC11B-PPS-SR
    Pack Content 5000pcs.
    Package Content packed in bag
    Type CC11B
    Height (H) 20.60mm
    Length (L) 30.0mm
    Panel Thickness 0.02 - 0.23"
    Panel Thickness max. 0.6 - 6.0mm
    Panel Thickness max. (imperial) 0.23"
    Panel Thickness min. (imperial) 0.02"
    Width (W) 18.20mm
    for Hole ∅ (FH) 9.0 x 17.0 mm
    for Panel Thickness min - max 0.6 - 6 mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +150 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 4031026702438
    Packaging 1 - Height (m) 0.214m
    Packaging 1 - Length (m) 0.635m
    Packaging 1 - Qty 5000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.05177m³
    Packaging 1 - Weight (kg) 10.400001kg
    Packaging 1 - Width (m) 0.381m
    Packaging 3 - Height (m) 0.2159m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Qty 5000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.052m³
    Packaging 3 - Weight (kg) 11.59kg
    Packaging 3 - Width (m) 0.396875m
    Packaging 4 - Height (m) 1.145m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 60000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.099m³
    Packaging 4 - Weight (kg) 151.8kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121702
