Connector clip for hole (oval), EWCAP-005-11, silver, 5000pcs.
Art.-No. 151-01538
| CCOVAL-PPS-SR
|
Copied
- The fir tree branch design on all four sides makes a 360-degree interface with the panel, creating a more secure fit into the hole.
- The disc on the top of the fir tree covers the hole and minimizes the ingress of water and dirt.
- The oval hole fir tree fits 4 common automotive oval hole sizes.
- The specific connector slot on this part reduces rattle and movement of clip to the wire harness connector.
Request your individual offer now
Request quote
More products in this product group:
| Application | A clip to connect common connectors |
| Colour | Silver (SR) |
| Fixation Method | Fir Tree for oval holes |
| Material | Polyphenylene Sulfide (PPS) |
| PART DESCRIPTION | CCOVAL-PPS-SR |
| Pack Content | 5000pcs. |
| Package Content packed in | carton |
| Product Family | with fir tree |
| Product Group | Connector clips for oval holes |
| Type | CCOVAL |
| Height (H) | 19.98mm |
| Height (H2) | 12.83mm |
| Length (L) | 29.34mm |
| Panel Thickness | 0.02 - 0.27" |
| Panel Thickness max. | 0.6 - 6.75mm |
| Panel Thickness max. (imperial) | 0.27" |
| Panel Thickness min. (imperial) | 0.02" |
| Width (W) | 17.63mm |
| for Hole ⌀ (FH) | 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm |
| for Panel Thickness min - max | 0.6 - 6.8 mm |
Download
|
|
|
| GTIN-13 / EAN | 4031026545646 |
| Packaging 1 - Qty | 5000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Weight (kg) | 14.000001kg |
| Packaging 3 - Height (m) | 0.20002499999999998m |
| Packaging 3 - Length (m) | 0.51117499999999995m |
| Packaging 3 - Qty | 5000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0318m³ |
| Packaging 3 - Weight (kg) | 7.36kg |
| Packaging 3 - Width (m) | 0.31115m |
| Packaging 4 - Height (m) | 1.219m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 100000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.17m³ |
| Packaging 4 - Weight (kg) | 313.2kg |
| Packaging 4 - Width (m) | 0.8m |
