P-clamp closed, Dmax=17.5mm, ⌀4.2 mm, black, 1000pcs.
Art.-No. 211-60110
| H10P-PA66HS-BK
|
Details
- Manufactured from Polyamide
- Good temperature resistance and high strength
- Wide range of sizes for every application
- Can be used without cable ties
More products in this product group:
| Application | For permanent or semi-permanent cable fixings this range of plastic P-Clamps can be used in many industries. Their light weight makes them particularly suitable for use in areas such as aircraft and aerospace where minimising weight, but retaining a strong fixing, is vitally important. |
| Colour | Black (BK) |
| Fixation Method | screw-hole |
| Material | Polyamide 6.6, heat stabilised (PA66HS) |
| PART DESCRIPTION | H10P-PA66HS-BK |
| Pack Content | 1000pcs. |
| Package Content packed in | bag |
| Product Family | HP-Series |
| Product Group | Plastic P-Clamps |
| Type | H10P |
| Variant | Closed |
Download
| Flammability | UL 94 V2 |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
|
|
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability. Sustainable by design focuses on product solutions that reduce waste, improve longevity or support subsequent reuse and recyclability. |
| UV-Stabilised | No |
| GTIN-13 / EAN | 4031026231631 |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Weight (kg) | 1.3000kg |
| Packaging 2 - Qty | 1 |
| Packaging 3 - Height (m) | 0.35m |
| Packaging 3 - Length (m) | 0.59m |
| Packaging 3 - Qty | 4000 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.0392m³ |
| Packaging 3 - Weight (kg) | 5.70kg |
| Packaging 3 - Width (m) | 0.19m |
| Packaging 4 - Height (m) | 1.05m |
| Packaging 4 - Length (m) | 1.18m |
| Packaging 4 - Qty | 96000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 0.942m³ |
| Packaging 4 - Weight (kg) | 156.0kg |
| Packaging 4 - Width (m) | 0.76m |
H10P-PA66HS-BK
211-60009
