01/03/2025

Connector clip, EWCAP-005-7, grey/black, 4000Carton
Art.-No. 151-02996 | SAHOVAL1.4TCC7-PA66HIRHS/TPE-BK/GY |

Copied
Once installed, perpendicular arrowhead arms reduce movement and will not collapse when exposed to water or load.

    • Connector clips provide a single method to mount connectors to various surfaces in a variety of applications.
    • Highly engineered designs feature anti-rattle discs, anti-rotation oval fir trees and clamps for mounting on edges.
    • A wide assortment of styles is available to fit the variety of connector slot designs made by most of the largest global connector manufacturers.
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Grey (GY), Black (BK)
    Fixation Method arrowhead
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Thermoplastic Elastomer (TPE)
    PART DESCRIPTION SAHOVAL1.4TCC7-PA66HIRHS/TPE-BK/GY
    Pack Content 4000Carton
    Package Content packed in box
    Type SAHOVAL1.4TCC7
    Type of connection USCAR7
    Variant 6.2 x 12.2 mm
    6.5 x 12.5 mm
    6.5 x 13.0 mm
    Height (H) 17.55mm
    Length (L) 27.28mm
    Panel Thickness 0.05 - 0.07"
    Panel Thickness max. 1.2 - 1.8mm
    Panel Thickness max. (imperial) 0.07"
    Panel Thickness min. (imperial) 0.05"
    Width (W) 22.78mm
    for Hole ⌀ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm
    for Panel Thickness min - max 1.2 - 1.8 mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant No
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised No
    GTIN-13 / EAN 4031026702506
    Packaging 3 - Height (m) 0.212725m
    Packaging 3 - Length (m) 0.51435m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0347m³
    Packaging 3 - Weight (kg) 8.48kg
    Packaging 3 - Width (m) 0.3175m
    Packaging 4 - Qty 80000
    UNSPSC Key 31162305
