Bundling clip for hole (oval), L=50.0mm, SO=20.0mm, black, 1000pcs.
Art.-No. 151-02262
| SOC13FTOVAL-PA66HIRHS-BK
|
Details
- Simple installation, tool-free
- Is attached to the bundle element with cable ties or adhesive tape
- The oval base geometry serves as anti-twist protection and for defined cable routing
Request your individual offer now
Request quote
More products in this product group:
| Application | These bundling clips are mainly used in the automotive industry, particularly for the assembly of cable harnesses. They offer a simple and user-friendly method for fastening cables, hoses and pipes. |
| Colour | Black (BK) |
| Fixation Method | Fir Tree for oval holes |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | SOC13FTOVAL-PA66HIRHS-BK |
| Pack Content | 1000pcs. |
| Package Content packed in | carton |
| Product Family | Oval holes |
| Product Group | Bundling Clips with Fir Tree for Distance Routing |
| Type | SOC13FTOVAL |
| Bundling Bar Length | 50.0mm |
| Fixing Hole Shape | Oval |
| Length (L) | 50.0mm |
| Length (L2) | 20.0mm |
| Offset Length | 20.0mm |
| Panel Thickness | 0.02 - 0.16" |
| Panel Thickness max. | 0.6 - 4.0mm |
| Panel Thickness max. (imperial) | 0.16" |
| Panel Thickness min. (imperial) | 0.02" |
| for Hole ∅ (FH) | 6.5 x 12.5 mm |
| for Panel Thickness min - max | 0.6 - 4 mm |
Download
|
|
|
| GTIN-13 / EAN | 4031026491226 |
| Packaging 1 - Height (m) | 0.095m |
| Packaging 1 - Length (m) | 0.395m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.01689m³ |
| Packaging 1 - Weight (kg) | 2.102135kg |
| Packaging 1 - Width (m) | 0.45m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 6000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 13.43281kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.249m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 72000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.199m³ |
| Packaging 4 - Weight (kg) | 182.184kg |
| Packaging 4 - Width (m) | 0.8m |
