Bundling clip for hole (round), L=61.0mm, SO=15.9mm, natural, 2500pcs.
Art.-No. 151-02432
| SOC8FT8-PA66HIRHS-NA
|
Details
| Bundling Bar Length | 2.40" |
| Bundling Bar Length | 61.0mm |
| Height (H) | 22.4mm |
| Length (L) | 61mm |
| Length (L2) | 15.9mm |
| Offset Length | 15.9mm |
| Panel Thickness | 0.02 - 0.22" |
| Panel Thickness max. | 0.6 - 5.5mm |
| Panel Thickness max. (imperial) | 0.22" |
| Panel Thickness min. (imperial) | 0.02" |
| Width (W) | 12.0mm |
| for Hole ∅ (FH) | 7.6 - 10.0 mm, M10 x 1.5 |
| for Panel Thickness min - max | 0.6 - 5.5 mm |
Download
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +110 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | No |
|
|
|
| GTIN-13 / EAN | 4031026702247 |
| Packaging 1 - Qty | 2500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Weight (kg) | 4.600001kg |
| Packaging 3 - Height (m) | 0.212725m |
| Packaging 3 - Length (m) | 0.51435m |
| Packaging 3 - Qty | 2500 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.0347m³ |
| Packaging 3 - Weight (kg) | 6.06kg |
| Packaging 3 - Width (m) | 0.3175m |
| Packaging 4 - Height (m) | 1.219m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 50000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.17m³ |
| Packaging 4 - Weight (kg) | 124.0kg |
| Packaging 4 - Width (m) | 0.8m |
