Connector clip for hole (oval), EWCAP-005-11, black, 500pcs.
Art.-No. 151-00513
| YCCSFT62122-PA66HIRHS-BK
|
Details
Request your individual offer now
Request quote
More products in this product group:
| Anti rotation (Yes / No) | YES |
| Colour | Black (BK) |
| Fixation Method | arrowhead |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | YCCSFT62122-PA66HIRHS-BK |
| Pack Content | 500pcs. |
| Package Content packed in | bag |
| Product Group | Connector Clips for Oval Holes |
| Type | YCCSFT62122 |
| Disc ∅ | 0.87" |
| Disc ∅ | 22.0mm |
| Fixing Hole Shape | Oval |
| Height (H) | 14.1mm |
| Length (L) | 27.5mm |
| Panel Thickness | 0.02 - 0.04" |
| Panel Thickness max. | 0.6 - 1.0mm |
| Panel Thickness max. (imperial) | 0.04" |
| Panel Thickness min. (imperial) | 0.02" |
| Width (W) | 16.0mm |
| for Hole ∅ (FH) | 6.2 x 12.2 mm |
| for Panel Thickness min - max | 0.6 - 1 mm |
Download
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | No |
|
|
|
| GTIN-13 / EAN | 4031026277202 |
| Packaging 1 - Height (m) | 0.3m |
| Packaging 1 - Length (m) | 0.625m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0825m³ |
| Packaging 1 - Weight (kg) | 0.551478kg |
| Packaging 1 - Width (m) | 0.44m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 15000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 17.36434kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.249m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 180000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.199m³ |
| Packaging 4 - Weight (kg) | 229.2kg |
| Packaging 4 - Width (m) | 0.8m |
