19/12/2024
Available individually “without cable ties” only as consumables for the ATS flex.

Cable tie mount, T=0.6-6.75mm, ∅6.2 x 12.2 mm/6.5 x 12.5 mm, black, 5000pcs.
Art.-No. 102-67073 | ATS-FTOVAL12.5A-PA66HIRHS-BK |  Details

Fixing elements for automatic bundling.

    • Clips to fix cables and harnesses in the automotive and white goods industries
    • Optimized for use automatic cable tying systems
    • Easy to apply
    • The fixing elements can be tied automatically with Autotool System
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Fixation Method with Fir Tree (Mounts)
    Internet Customer Notice Available individually “without cable ties” only as consumables for the ATS flex.
    Key product features products for automatic tools
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION ATS-FTOVAL12.5A-PA66HIRHS-BK
    Pack Content 5000pcs.
    Package Content packed in bag
    Product Family Fir tree clips for automatic cable tying systems
    Product Group Automatic bundling
    Type ATS-FTOVAL12.5A
    Height (H) 24.82mm
    Length (L) 23.63mm
    Panel Thickness max. 0.6-6.75mm
    Width (W) 17.63mm
    for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 6.8 mm
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026651378
    UNSPSC Key 39121717
