Low Voltage End Cap PO-X black
Art.-No. 416-02008
| 1602-1-B5W2-PO-X-BK
|
Details
- Seal cables during storage or transportation
- Insulating cap for live LV cables (0.6/1kV)
- Adhesive lining for excellent environmental seal
- High shrink ratio to minimise number of sizes needed
- Can be fitted with air valves for pressurised cable applications
- High shrink ratio to minimise number of sizes needed
More products in this product group:
| Application | End caps are suitable for use on both polymeric and paper insulated, lead jacketed cables which may include aluminium or steel armouring. |
| Colour | Black (BK) |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | 1602-1-B5W2-PO-X-BK |
| Pack Content | 400pcs. |
| Package Content packed in | box |
| Product Family | Helashrink 1600 Series, low voltage |
| Product Group | End Caps |
| Shrink Ratio | up to 3:1 |
| Type | 1602-1-B5W2 |
Download
|
|
|
| GTIN-13 / EAN | 5022660645853 |
| Packaging 1 - Height (m) | 0.08m |
| Packaging 1 - Length (m) | 0.24m |
| Packaging 1 - Qty | 40 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00355m³ |
| Packaging 1 - Weight (kg) | 0.320001kg |
| Packaging 1 - Width (m) | 0.185m |
| Packaging 3 - Height (m) | 0.37m |
| Packaging 3 - Length (m) | 0.415m |
| Packaging 3 - Qty | 400 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.0507m³ |
| Packaging 3 - Weight (kg) | 2.578kg |
| Packaging 3 - Width (m) | 0.33m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 7200 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Weight (kg) | 67.404kg |
| Packaging 4 - Width (m) | 0.8m |
