FU16-M16-M-NPB-ML
Art.-No. 166-90762 | FU16-M16-M-NPB-ML |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Metal (ML)
    Material Nickel Plated Brass (NPB)
    PART DESCRIPTION FU16-M16-M-NPB-ML
    Pack Content 10pcs.
    Package Content packed in pack
    Thread type metric
    Type FU16-M16-M
    Variant Straight
    Bore Diameter (Imperial) 0.45"
    Bore Diameter (metric) 11.5
    Height (H) 20.0mm
    Length (L) 25.0mm
    Nominal ∅ 0.38"
    Nominal ∅ 16.0mm
    Thread Length (TL) 10mm
    Thread Length (TL) (Imperial) 0.39"
    Thread Size M16
    Wrenching Flat Size (Imperial) 0.98"
    Wrenching Flat Size (Metric) 25.0mm
    CE Certification No
    CSA Certified No
    Halogen-free Yes
    IP-Rating IP40
    Operating Temperature -50 °C to +300 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 4031026570280
    UNSPSC Key 39131707
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
