23/12/2024

LTPPU40B-10M-GS/PUR-BK
Art.-No. 166-90719 | LTPPU40B-10M-GS/PUR-BK |  Details

Flexible metallic conduit provides liquid-tight performance to IP66 + IP67 + IP68 + IP69 when used with LTP or LTPUL fittings.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Material Galvanised Steel (GS), Polyurethane resin (PUR)
    PART DESCRIPTION LTPPU40B-10M-GS/PUR-BK
    Pack Content 10.0m
    Package Content packed in reel
    Type LTPPU40B-10M
    Bending Radius min. (R) 175mm
    Diameter (D) 35.4mm
    Length (L) 10.0m
    Nominal ∅ 1.25"
    Nominal ∅ 40.0mm
    Outside Ø (OD) 41.8mm
    Outside ∅ (OD) 1.65"
    Weight 885g/m
    ∅ D 1.39"
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V0
    Halogen-free Yes
    Operating Temperature -40 °C to +100 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 4031026562322
    Packaging 1 - Weight (kg) 8.85kg
    Reel Length 32.8ft
    Reel Length 10.0m
    UNSPSC Key 39131706
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
