22/12/2024

LTSHSSB32-GS/PO/SS-ML
Art.-No. 166-34904 | LTSHSSB32-GS/PO/SS-ML |  Details

The HelaGuard PCSB galvanised steel conduit with a PVC coating galvanised steel overbraid offers high abrasion resistance and EMC screening.

    • Galvanised steel, helically wound, flexible conduit with thermoplastic elastomer cover and stainless steel (316) overbraid
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Metal (ML)
    Conduit Model with EMI shielding
    Material Galvanised Steel (GS), Polyolefin (PO), Stainless Steel (SS)
    PART DESCRIPTION LTSHSSB32-GS/PO/SS-ML
    Pack Content 25m
    Package Content packed in reel
    Type LTSHSSB32
    Bending Radius min. (R) 80mm
    Diameter (D) 26.5mm
    Inside Ø (ID) 26.5mm
    Nominal ∅ 1.25"
    Nominal ∅ 32mm
    Outside Ø (OD) 34.6mm
    CE Certification Yes
    IP-Rating IP66 (in conjunction with HG fittings)
    Operating Temperature -45 °C to +135 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026327716
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
