HG-DC0500-PP-BK
Art.-No. 166-90984 | HG-DC0500-PP-BK Details

  • Double slit conduit opening offers easy access during installation and maintenance.
  • Overlapping conduit design increases mechanical protection and eliminates unintentional exposure of wires caused by motion, vibration or when routed around corners.
  • Material is easy to use and cut - reduces installation time and labor costs.
  • Good impact strength, recovers quickly if crushed.
  • Flexible, abrasion resistant and durable for a variety of applications.
Show more

Request your individual offer now

Colour Black (BK)
Description A standard weight polypropylene corrugated conduit with two slit openings that eases installation and maintenance of wire and cable bundles. The interlocking construction is excellent for retrofitting projects. Polypropylene material is typically used in building construction, particulaly where buried in concrete or plaster.
Material Polypropylene (PP)
PART DESCRIPTION HG-DC0500-PP-BK
Pack Content 50m
Package Content packed in reel
Pitch Type coarse
Type HG-DC0500
Bending Radius min. (BR) 4.73"
Bending Radius min. (R) 120mm
Inner Diameter D (Imperial) 0.55"
Inside Ø (ID) 13.9mm
Length (L) 50m
Nominal ∅ 0.5"
Nominal ∅ 21mm
Outside Ø (OD) 21.2mm
Outside ∅ (OD) 0.84"
CE Certification No
CSA Certified No
Flammability EN IEC 61386
Halogen-free No
Operating Temperature -20 °C to +90 °C
ROHS compliant Yes
Self extinguishing Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
GTIN-13 / EAN 4031026663449
Reel Length 164.0ft
Reel Length 50.0m
UNSPSC Key 39131601
