HGU42-S-M50B-PA66-BK
Art.-No. 166-90800 | HGU42-S-M50B-PA66-BK |  Details

All-around

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION HGU42-S-M50B-PA66-BK
    Pack Content 2pcs.
    Package Content packed in pack
    Swivel Thread (Y/N) No
    Thread type metric
    Type HGU42-S-M50B
    Variant Straight
    Bore Diameter (Imperial) 1.59"
    Bore Diameter (metric) 40.5
    Length (L) 60.96mm
    Nominal ∅ 1.65"
    Nominal ∅ 42.0mm
    Outside Ø (OD) 60.0mm
    Outside ∅ (OD) 2.36"
    Thread Length (TL) 16.0mm
    Thread Length (TL) (Imperial) 0.63"
    CE Certification No
    CSA Certified No
    Halogen-free Yes
    IP-Rating IP68
    Operating Temperature -50 °C to +135 °C
    ROHS compliant Yes
    Self extinguishing Yes
    Specifications
    UL Listed (US and Canada) Yes
    UL Listed (US and Canada) Yes
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UL-File Number E247502
    UV-Stabilised No
    GTIN-13 / EAN 4031026588155
    UNSPSC Key 39131601
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!

    Metal conduits >
    Convoluted tubing Convoluted tubing

    Corrugated tubing

    Whether thin- or thick-walled, enclosed or slit: Find now the right corrugated tubing, including matching fitting and holder.

    Corrugated tubing >
