Accessory, Helawrap, black, 50pcs. (HWBASE)
Art.-No. 161-64015 | HWBASE-PA66HIRHS-BK |  Details

HelaWrap - HWBASE - screw mount base.

    • Mounting plates can be fixed with screws, cable ties or adhesive
    • Can be used to mount any size HWClip
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application To complete the Helawrap cable management system various Helawrap Clips in compatible sizes are available. The mounting clips can be combined and adjusted individually. Attached to a mounting base the assembly can be screw mounted or directly sticked to the surface.
    Colour Black (BK)
    Fixation Method screw-hole
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION HWBASE-PA66HIRHS-BK
    Pack Content 50pcs.
    Package Content packed in bag
    Product Family HWBase
    Product Group Acessories for retaining Helawrap Open Cable Cover
    Type HWBASE
    Length (L) 38mm
    Width (W) 38mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Melting Point +284 °F (+140 °C)
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026575513
    Packaging 1 - Height (m) 0.02m
    Packaging 1 - Length (m) 0.25m
    Packaging 1 - Qty 50
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.0011m³
    Packaging 1 - Weight (kg) 0.161729kg
    Packaging 1 - Width (m) 0.22m
    Packaging 3 - Height (m) 0.171m
    Packaging 3 - Length (m) 0.56m
    Packaging 3 - Qty 1000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0172m³
    Packaging 3 - Weight (kg) 3.57858kg
    Packaging 3 - Width (m) 0.18m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 48000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 192.744kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39131604
