Cable label, White/Transparent
Art.-No. 590-05140 | RO514-100B-CL/WH |  Details

Dispenser edge allows easy removal of label liner.

    • Compact to easily fit in pants or shirt pockets
    • Dispenser can be reloaded over and over, making it cost effective to use
    • Dispenser edge allows easy removal of label liner
    • Dispenser protects labels from dirt and moisture before use, extending the life and quality of the labels
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application RiteOn Dispenser Pack The ideal way of starting to use HellermannTyton’s excellent hand held labelling products. Refill Packs Refill packs are available with label areas in 6 different colours that will suit most applications. Refilling is simplicity itself into the RiteOn dispenser. Marking Pen Permanent marker pens are available for reliable labelling. The indelible ink will not wash off and dries very quickly. Available in pairs in either black or red.
    Colour White (WH), Transparent (CL)
    Colour Marking Field White (WH)
    Description HellermannTyton’s Rite-On Markers are made from a flexible vinyl film and used to mark wire and cable. The self-laminating labels have a clear tail which seals the legend under clear vinyl, maintaining the quality of the labels. The Rite-On markers are packaged in a reusable dispenser made from high impact plastic which is resistant to oils and grease.
    Fixation Method Pasting / Stick
    Material Type 100B, Vinyl, white transparent, self-laminating (100B)
    PART DESCRIPTION RO514-100B-CL/WH
    Pack Content 200pcs.
    Package Content packed in EA
    Product Group Hand Writable Labels
    Self adhesive (Yes/No) Yes
    Type RO514
    Variant Roller form
    With label space Yes
    Bundle Diameter max (metric) 6.68mm
    Bundle ∅ min. 3.89mm
    For AWG 9 to 2/0
    Height (H) 9.5mm
    Height (H2) 31.75mm
    Min. Wire Size (in²) 0.10"
    Outside ∅ max (OD max.) 6.68mm
    Outside ∅ max. 0.263"
    Outside ∅ min. 0.153"
    Outside ∅ min. (OD min.) 3.89mm
    Print Method manual marking
    Width (W) 19.05mm
    Adhesive Acrylic
    Adhesive Operating Temperature -40 °C to +80 °C
    CE Certification No
    CSA Certified No
    Curing Temperature from +10 °C
    Halogen-free No
    Operating Temperature -40 °C to +80 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) Yes
    UL-File Number MH18396
    UV-Stabilised No
    GTIN-13 / EAN 4031026172248
    Packaging 1 - Weight (kg) 0.1kg
    Packaging 4 - Length (m) 1.20m
    Packaging 4 - Type pallet
    Packaging 4 - Width (m) 0.80m
    UNSPSC Key 39131509
    Cable labels, wire labels for industrial identification Cable labels, wire labels for industrial identification

    Cable labels, wire labels for industrial identification

    You are looking for cable labels, wire labels or cable tags? HellermannTyton offers a wide range of identification solutions for industrial use.
