21/11/2024

Cable tie inside serrated, 203.2x4.6mm, ∅1.5-50.0mm, blue, 100pcs.
Art.-No. 111-00830 | MCT50R-PA66MD-BU |  Details

    • Total metal dispersion throughout the tie
    • Can support quality assurance in the production of food stuffs, for example HACCP
    • Blue colour for easy visual detection
    • Greatly reduces risk of contamination
    • Magnetic detectable (detection level depending on specific application and equipment)
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The Metal Content Tie is a cable tie specifically designed for use in the food and pharmaceutical processing industries. A unique manufacturing process, involving the inclusion of a metallic pigment, enables even small 'cut-off' sections of the tie to be detected by standard metal-detecting equipment. Ideally suited for the installaton of cabling in and around the manufacturing process.
    Colour Blue (BU)
    Fixation Method Cable Tie
    Identification Plate Position none
    Key product features detectable
    Material Polyamide 6.6, metal detectable (PA66MD)
    PART DESCRIPTION MCT50R-PA66MD-BU
    Pack Content 100pcs.
    Package Content packed in bag
    Product Family MCT-Series, PA66MP
    Product Group Cable ties for food industry, detectable
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type MCT50R
    Variant Inside Serrated
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ min. 1.5mm
    Cable Tie Head Height (metric) 5.7mm
    Cable Tie Head Length (metric) 7.2mm
    Cable Tie Head Width (metric) 7.8mm
    Length (L) 203.2mm
    Min.Tensile Strength 225N
    Strap Width max. (G) 0.31"
    Thickness (T) 1.2mm
    Width (W) 4.6mm
    CE Certification Yes
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 5022660330698
    Packaging 1 - Height (m) 0.035m
    Packaging 1 - Length (m) 0.246m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00117m³
    Packaging 1 - Weight (kg) 0.160001kg
    Packaging 1 - Width (m) 0.136m
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Qty 6000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Weight (kg) 10.402kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.235m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 120000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.186m³
    Packaging 4 - Weight (kg) 229.04kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121703
