Fixing tie for hole (round), outside serrated, ∅2.0-50.0mm, black, 500pcs.
Art.-No. 157-00197 | T50ROSFT6S25SO-PA66HIRHSUV-BK |  Details

The fir tree mount cable tie is an all-in-one bundling and fastening solution that reduces costs and assembly time.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T50ROSFT6S25SO-PA66HIRHSUV-BK
    Pack Content 500pcs.
    Package Content packed in carton
    Product Family With offset 12.5 and 25.0 mm
    Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes
    Releasable Closure (Yes/No) No
    Type T50ROSFT6S25SO
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ min. 2.0mm
    Disc ∅ 0.75"
    Disc ∅ 19.0mm
    Length (L) 242.2mm
    Length (L2) 25.0mm
    Min.Tensile Strength 225N
    Offset Length 25.0mm
    Panel Thickness 0.02 - 0.15"
    Panel Thickness max. 0.6 - 3.75mm
    Panel Thickness max. (imperial) 0.15"
    Panel Thickness min. (imperial) 0.02"
    Width (W) 5.1mm
    for Hole ∅ (FH) 6.1 - 6.9 mm
    for Panel Thickness min - max 0.6 - 3.8 mm
    for Panel Thickness min - max 0 - 0.2 "
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026486406
    Packaging 1 - Height (m) 0.13m
    Packaging 1 - Length (m) 0.41m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.01652m³
    Packaging 1 - Weight (kg) 1.292001kg
    Packaging 1 - Width (m) 0.31m
    Packaging 3 - Height (m) 0.3730625m
    Packaging 3 - Length (m) 0.587375m
    Packaging 3 - Qty 2000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.063m³
    Packaging 3 - Weight (kg) 6.31kg
    Packaging 3 - Width (m) 0.2873375m
    Packaging 4 - Height (m) 1.27m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 24000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.219m³
    Packaging 4 - Weight (kg) 92.616kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121717
