Bi-Metal Lugs
Art.-No. 924-00875 | BML630-12-CU/AL-BN/ML Details

  • Suitable for aluminium conductor and copper terminals or busbar
  • Crimping compound in barrel and sealed with cap
  • Funnel entry to suit flexible cable
  • Chambering 30 degrees

Request your individual offer now

Application A bi-metal lug is used to connect Aluminum (AL) to copper (CU) Busbar. A bi-metal lug is crucial for ensuring a secure, corrosion-resistant, and efficient connection between aluminum and copper conductors in electrical systems. The Lugs are made from the highest quality aluminum and copper and are joined using a friction welding process. The HellermannTyton Lugs comply with the Australian and New Zealand Standard AS/NZS 4325 Part 1:1995. A crimping tool is recommended for this application.
Colour Aluminium (AL), Light Brown (LTBN)
Description Bi-Metal Lug 630mm² M12 Stud
Material Copper (CU), Aluminium (AL)
PART DESCRIPTION BML630-12-CU/AL-BN/ML
Pack Content 1pc.
Package Content packed in pcs.
Product Family BML-series, Aluminium to Copper
Product Group Bi-Metal Lugs
Type BML630-12
A/F Thread (A/F2) 43.2mm
Inside Ø (ID) 34mm
Length (L) 175mm
Length (L2) 90mm
Length (L3) 70mm
Offset Length 68mm
Outside Ø (OD) 54mm
Thickness (T) 10mm
Width (W) 60mm
for Hole ∅ (FH) M12
Operating Temperature -40 °C to +100 °C
Specifications
Specifications AS/NZS4325 Part 1
Tensile Strength 205MPa
