Fixing tie for hole (oval), outside serrated, ∅1-33mm, black, 500pcs.
Артикулен 126-00285 | OS180SFT712-E-PA66HS-BK Подробности

  • Easy to install without the need for a tool
  • Arrowhead simply locks into place
  • Disc adjusts tie for pressures from various directions and minimises access of dust and dirt
  • Cable tie head always situated in a defined position
  • Versions for oval holes feature anti-twist protection
покажи повече

Заявете вашата индивидуална оферта сега

Application With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building.
Application Tool ProCut 9 no battery, EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9SP, EVO9HT, EVO9i, EVO9iSP, EVO9iHT
Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
Colour Black (BK)
Fixation Method Arrowhead for oval holes
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION OS180SFT712-E-PA66HS-BK
Pack Cont. 500pcs.
Package Content packed in bag
Product Family for oval holes
Product Group 1-piece fixing ties with arrowhead, with disc
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type OS180SFT712-E
Bundle Diameter max (metric) 33mm
Bundle ∅ min. 1mm
Disc ∅ 16.3mm
Fixing Hole Shape Oval
Height (H) 1.5mm
Length (L) 182mm
Min.Tensile Strength 225N
Thickness (T) 1.5mm
Width (W) 5.1mm
for Hole ∅ (FH) 7.0 x 12.0 mm
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Country of Origin KR
GTIN-13 / EAN 4031026567754
UNSPSC Key 39121703
