Cable tie outside serrated, 100.0x2.5mm, ∅1.6-20.0mm, black, 100pcs.
Číslo dílu 118-04700
| T18ROS-PA66HS-BK
|
Podrobnosti na
- Outside serrated cable tie with smooth surface to the bundle
- Tie follows the contours of the cable bundle perfectly
- Takes up less space due to curved head design
- Easy insertion combined with high tensile strength
- PA46 material for higher temperatures up to +195 °C (500 h)
- PA66V0 cable ties fulfill Limited Fire Hazard requirements
- Easy application either manually or with a processing tool
Více výrobků v této skupině výrobků:
| Application | OS-Series cable ties are used in many areas where thin-walled or soft insulation wires and cable are being installed, for instance automotive and aircraft industry. OS ties manufactured from PA66V0 material are suitable for applications where safety regulations require reduction of smoke and dangerous gases. |
| Colour | Black (BK) |
| Identification Plate Position | none |
| Material | Polyamide 6.6, heat stabilised (PA66HS) |
| PART DESCRIPTION | T18ROS-PA66HS-BK |
| Pack Cont. | 100pcs. |
| Package Content packed in | bag |
| Product Family | OS-Series |
| Product Group | Cable ties for thin-walled bundles |
| Releasable Closure (Yes/No) | No |
| Short Description | Cable Tie outside serrated 100x2.5 mm, heat stabilised, black |
| Tie Closure | plastic pawl |
| Type | T18ROS |
| Variant | Outside Serrated |
|
|
| Bundle Diameter max (metric) | 20.0mm |
| Bundle ∅ | 1.6-20.0mm |
| Bundle ∅ min. | 1.6mm |
| Cable Tie Head Height (metric) | 4mm |
| Cable Tie Head Length (metric) | 5.1mm |
| Cable Tie Head Width (metric) | 5.1mm |
| Height (H) | 1.0mm |
| Length (L) | 100.0mm |
| Min.Tensile Strength | 80N |
| Strap Width max. (G) | 0.2" |
| Thickness (T) | 1mm |
| Weight/Unit | 0.00028kg |
| Width (W) | 2.5mm |
Stáhnout
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 V2 |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
| UV-Stabilised | No |
|
|
|
| Country of Origin | GB |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 5022660320248 |
| Packaging 1 - Height (m) | 0.022m |
| Packaging 1 - Length (m) | 0.135m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0004m³ |
| Packaging 1 - Weight (kg) | 0.030001kg |
| Packaging 1 - Width (m) | 0.136m |
| Packaging 3 - Height (m) | 0.192m |
| Packaging 3 - Length (m) | 0.586m |
| Packaging 3 - Qty | 25000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0439m³ |
| Packaging 3 - Weight (kg) | 8.30225kg |
| Packaging 3 - Width (m) | 0.39m |
| Packaging 4 - Height (m) | 1.164m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 500000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.117m³ |
| Packaging 4 - Weight (kg) | 187.04kg |
| Packaging 4 - Width (m) | 0.8m |
