RFID reader, desktop, 13.56 MHz (HF), 1pc.
Číslo dílu 556-00707
| RFID-PNR-HF-R-ABS-BU
|
Podrobnosti na
Tento výrobek již není k dispozici.
- RFID desktop reader
- High frequency (HF – 13.56 MHz)
- For reading and writing of data
- USB, HID interface
- Operator convenience
- Lightweight and handy design
Vyžádejte si nyní individuální nabídku
Vyžádat nabídku
Více výrobků v této skupině výrobků:
| Application | The RFID-PNR-HF-R is a high frequency desktop reader and designed to read HF RFID transponders (13.56 MHz) as easily as a barcode. The reading and transmission of data is extremely fast. RFID-PNR-HF-R is directly ready for use with most applications- no driver installation is required. Simply click in the cell to add data from the RFID transponder, and the data is automatically entered into the cell. RFID system solutions can make a significant contribution to improving the process reliability and quality in a variety of industries. |
| Colour | Blue (BU) |
| Connection for external antenna | No |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| PART DESCRIPTION | RFID-PNR-HF-R-ABS-BU |
| Pack Cont. | 1pc. |
| Package Content packed in | box |
| Product Family | RFID desktop readers/writers – High frequency (HF) |
| Product Group | RFID readers and/or writers |
| Short Description | RFID desktop reader (13.56 MHz) 79x79x30 mm |
| Transmission range max. | 120mm |
| Transmission rate reading max. | 848Kbps |
| Transmission rate writing max. | 848Kbps |
| Type | RFID-PNR-HF-R |
| Type of electric connection | Plug-in connection |
| Type of voltage (input voltage) | DC |
| ELV compliant (Article 4 - 2) | YES |
| Hazardous Goods | No |
| Interfaces | USB, HID |
| Operating Temperature | -20 °C to +70 °C |
| ROHS compliant | Yes |
| Radio protocol | ISO 15693 |
| Specifications |
|
| Specifications | directives 2004/108/EC, directives 2014/30/EU, EN 300330-2:06-2015, EN 301489-1:03-2012 / 2013, EN 302291-1, EN 50364:07-2010, EN 50581:2012, FCC part 15 class B, Low voltage directive 2006/95/CE, Low voltage directive 2014/35/EU, WEEE European directive 2012/19/EC |
