RFID label, 860-960 MHz (UHF), white, 130.00x50.00mm, 1000pcs.
Číslo dílu 556-00847
| TAG130x50T1UHF-1603-WH
|
Podrobnosti na
- The bundling label with integrated RFID transponder (UHF / 860 - 960 Mhz) is ideal for temporary, unique identification and digital management of cable harnesses and wire harnesses.
Vyžádejte si nyní individuální nabídku
Vyžádat nabídku
Více výrobků v této skupině výrobků:
| Application | This bundling label with integrated RFID transponder is ideally suited for the temporary unique identification and digital management of cable harnesses and wire harnesses. Thanks to the so-called UID (Unique Identifier, Unique Identification Number) and its integrated and freely usable data memory, objects can be inventorised, tracked and monitored in a simple manner within the framework of asset management (resource management, maintenance) or the manufacturing execution system (production control system) or of supply chain management (purchasing, warehouse management, transport). With the help of an IT infrastructure, specific information can be assigned to each individual object or location, which can be called up as required and thus serve to optimize processes. This has an immediate positive effect on the process costs. |
| Application Method | The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance. |
| Colour | White (WH) |
| Key product features | detectable |
| Material | Type 1603, Polyester (1603) |
| PART DESCRIPTION | TAG130x50T1UHF-1603-WH |
| Pack Cont. | 1000pcs. |
| Package Content packed in | reel |
| Product Family | RFID label type 1603 – Ultra high frequency (UHF) |
| Product Group | Bundling labels with integrated RFID transponder, thermal transfer |
| Removable | No |
| Self adhesive (Yes/No) | Yes |
| Short Description | RFID bundling label 130x50 mm UHF white |
| Type | TAG130x50T1UHF |
Stáhnout
| Country of Origin | DE |
| Customs Number | 85235910 |
| GTIN-13 / EAN | 4031026659442 |
| Packaging 1 - Height (m) | 0.055m |
| Packaging 1 - Length (m) | 0.2m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | reel |
| Packaging 1 - Volume (m³) | 0.0022m³ |
| Packaging 1 - Weight (kg) | 0.3kg |
| Packaging 1 - Width (m) | 0.2m |
| Storage Temperature | +20 °C |
| Storage conditions | 50% relative humidity. |
