RFID label, 840-960 MHz (UHF), white, 254.00x74.00mm, 550pcs.
Číslo dílu 556-00848
| TAG254x74UHF-1604-WH
|
Podrobnosti na
- Identification card with integrated RFID transponder according to international standards
- Backing material made of sturdy cardboard
- Can be printed with the help of thermal transfer printer
- Executed on a reel
- Designed for insertion in the identification compartment of small load carriers
- Clear identification of objects and / or locations through unique numbering systems
- Faster, more secure and error-free data management
- Robust and durable with data retention
- Large range of functionalities according to corresponded infrastructure (hardware, software)
- Different colours available
![](https://www.hellermanntyton.com/shared/speclogos/99595_All_Languages.jpg)
Vyžádejte si nyní individuální nabídku
Vyžádat nabídku
Více výrobků v této skupině výrobků:
Application | This identification card with integrated RFID transponder (UHF / 860 - 960 Mhz) is ideal for temporary, unique identification and digital management of small load carriers and storage locations. Thanks to the so-called UID (Unique Identifier, Unique Identification Number) and its integrated and freely usable data memory, objects can be inventorised, tracked and monitored in a simple manner within the framework of asset management (resource management, maintenance) or the manufacturing execution system (production control system) or of supply chain management (purchasing, warehouse management, transport). With the help of an IT infrastructure, specific information can be assigned to each individual object or location, which can be called up as required and thus serve to optimize processes. This has an immediate positive effect on the process costs. |
Colour | White (WH) |
Fixation Method | Non-Adhesive |
Key product features | detectable |
Marking Text | Unprinted |
Material | Type 1604, Cardboard (1604) |
PART DESCRIPTION | TAG254x74UHF-1604-WH |
Pack Cont. | 550pcs. |
Package Content packed in | reel |
Product Family | RFID identification card type 1604 – Ultra high frequency (UHF) |
Product Group | Identification cards with integrated RFID transponder, thermal transfer |
Self adhesive (Yes/No) | No |
Short Description | RFID identification card 254x74 mm, 860-960 MHz (UHF), cardboard, white |
Type | TAG254x74UHF |
Curing Temperature | from +5 °C |
ELV compliant (Article 4 - 2) | YES |
Hazardous Goods | No |
Operating Temperature | -20 °C to +70 °C |
Pre-Printed | Yes |
ROHS compliant | Yes |
Radio protocol | ISO 18000-6C, EPC Gen2 |
Recommended Ribbon Type | TT822OUT |
Shelf Life | 12 months |
Specifications |
![]() |
Tamper proof | No |
Type of RFID chip | NXP Ucode 7 |
Write endurance | 100000 cycles |
Country of Origin | DE |
Customs Number | 85235910 |
GTIN-13 / EAN | 4031026659879 |
Labels per Row | 1pc. |
Packaging 1 - Height (m) | 0.079m |
Packaging 1 - Length (m) | 0.2m |
Packaging 1 - Qty | 550 |
Packaging 1 - Type | reel |
Packaging 1 - Volume (m³) | 0.00316m³ |
Packaging 1 - Weight (kg) | 0.165kg |
Packaging 1 - Width (m) | 0.2m |
Storage Temperature | +20 °C |
