Heat shrink marker, thermal transfer print, ladder-style, 26.0mm/8.4mm, W=48.26mm, white, 1700pcs.
Číslo dílu 553-50200
| HST24-8WH-PO-X-WH
|
Podrobnosti na
- Slide Slit and optional center slits for easy wire insertion.
- Smooth surface for clean and legible printing.
- Supplied on a ladder style carrier so that markers can be kitted after printing.
- A 3:1 shrink ratio means fewer skews as each marker covers a wider range of wire diameters.
Více výrobků v této skupině výrobků:
| Application | Shrinkable markers by thermal transfer. Ideal for applications where dialing cannot take up space or run on the cable. HellermannTyton ShrinkTrak Markers make it easy to identify wires, cables and other components. These markers are made with cuts in the side, which make it easy to apply to the cables. All ShrinkTrak labels are homologated for military use (American Standard). |
| Chem. Material Properties | Flexible, flame retardant, with good solvent resistance. |
| Colour | White (WH) |
| Material | Polyolefin, cross-linked (PO-X) |
| Mech. material properties | Flexible, flame retardant with side slits for easy marker removal |
| PART DESCRIPTION | HST24-8WH-PO-X-WH |
| Pack Cont. | 1700pcs. |
| Package Content packed in | box |
| Printable | Yes |
| Product Family | ShrinkTrak |
| Product Group | Shrinkable Wire Markers: "Ladder Style", thermal transfer |
| Shrink Ratio | 3:1 |
| Type | HST24-8WH |
| Variant | Thin-Wall |
| With inner glue (Yes/No) | No |
|
|
| Flexibility | Flexible |
| For AWG | 1-400 |
| H printable | 19.55mm |
| Height (H) | 19.55mm |
| Outside ∅ max (OD max.) | 25.4mm |
| Outside ∅ max. | 1.0" |
| Print Method | thermal transfer print |
| Recov. ∅ d max. | 0.33" |
| Recov. ∅ d max. | 8.4mm |
| Supplied ∅ D min. | 26.0mm |
| Supplied ∅ D min. | 1.024" |
| Thickness (T) | .0762mm |
| Wall (WT) | 0.039" |
| Wall (WT) | 1.0mm |
| Width (W) | 48.26mm |
| Width of LIner (WL) | 3.0" |
| Width of Liner (WL) | 76.2mm |
| Width printable | 48.26mm |
| Wire Size Range (mm²) | 0.33-0.876mm² |
| ∅ D max. | .50" |
| ∅ D max. | 12.70mm |
Stáhnout
| Abrasion Resistance | Medium |
| CE Certification | No |
| Dielectric Strength | 19.7kV/mm |
| Flammability | UL 224 VW-1 |
| Halogen-free | No |
| Min. Shrink Temperature - °C | +90 °C |
| Operating Temperature | -55 °C to +135 °C |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TTDTHOUT, TTDTHOUTSM, TT822OUT, TT822OUTSM |
| Reel Variant | ladder-style |
| Solvent Resistance | Good |
| Specifications |
|
| Specifications | UL 224 125 °C 600V VW-1 |
| US Gov. Designation | SAE-AMS-DTL-23053/5 Class 1 and 3, MIL-STD-202G Method 215K, SAE-AS81531 |
