Cable tie mount for screw fixation, Wmax=7.9mm, ∅5.1 mm, #10 (M5) Screw, white, 100pcs.
Art.-No. 151-30604 | CTM3-PA66-WH |  Details

    • Curved design for additional cable support
    • Simple to install with a screw or bolt
    • Excellent security, particularly in areas of high vibration
    • Mounts are available in various sizes and materials
    Package size
    Add to watchlist
    Downloads Datasheet
    Application Designed specifically for holding heavier cable bundles these mounting bases can be used in many industries from agriculture to truck manufacturing. They offer a very secure fixing and can be used with a wide variety of heavy duty cable ties up to 8.3 mm width.
    Colour White (WH)
    Fixation Method Screw Mounting and Rivet
    For Ties T18 - T120
    Material Polyamide 6.6 (PA66)
    Mounting Screw Type #10 (M5) Screw
    PART DESCRIPTION CTM3-PA66-WH
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family CTM with curved design for big bundle diameters
    Product Group Screw fixing mounts
    Type CTM3
    Height (H) 9.4mm
    Length (L) 21.8mm
    Strap Width max. (G) 0.31"
    Strap Width max. (G) 7.9mm
    Width (W) 15.5mm
    for Hole ∅ (FH) 5.1 mm
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V2
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Specifications UL 62275
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) Yes
    UL-File Number E64139
    Country of Origin MX
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.517525m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0344m³
    Packaging 3 - Width (m) 0.3175m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
