Cable tie mount, Wmax=19.1mm, black, 100pcs.
Art.-No. 151-04018 | MAGCTM15H-NDFEB39M/POM/ST-BK Details

Package size
Colour Black (BK)
Fixation Method Magnet
For Ties Grip Tie
Magnetic pull strength (N) 66N
Magnetic pull strength (kgf) 6.73
Magnetic pull strength (lb/ft) 15lbf-ft
Material Neodymium alloy 39M (NDFEB39M), Polyacetal (POM), Steel (ST)
PART DESCRIPTION MAGCTM15H-NDFEB39M/POM/ST-BK
Pack Cont. 100pcs.
Package Content packed in bag
Type MAGCTM15H
Diameter (D) 26mm
Height (H) 14.4mm
Rotation (°) 360°
Strap Width max. (G) 0.75"
Strap Width max. (G) 19.1mm
∅ D 1.02"
CE Certification No
CSA Certified No
Halogen-free Yes
Operating Temperature -40 °C to +80 °C
Plenum Rating AH-2
ROHS compliant Yes
Reusable (Yes/No) Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) Yes
UL Recognized (US and Canada) No
UL Recognized (US) No
UL-File Number E64139
Country of Origin US
GTIN-13 / EAN 4031026730189
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
