20/11/2024

Cable tie inside serrated, 340x7.6mm, ∅16.0-90.0mm, black, 100pcs.
Art.-No. 112-00100 | HT120R-PA66HS-BK |  Details

CTT ties installed on flexible gaiters.

    • Curved head design offers a good fit to the bundle
    • Inside serration for a strong hold onto bundles
    • Easy application either manually or with a processing tool
    Add to watchlist
    Downloads Datasheet e-Learning
    Application CTT is designed to secure pipes, hoses and gaiters where low pressures are being secured. These ties can be used in many different industries including automotive, white goods manufacturing, medical industry and construction.
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION HT120R-PA66HS-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family HT-Series up to 535 N loop tensile strength
    Product Group Cable ties for hose and gaiter
    Releasable Closure (Yes/No) No
    Short Description Cable Tie for hose and gaiter340x7.6 PA66HS black
    Tie Closure plastic pawl
    Type HT120R
    Variant Inside Serrated
    Bundle Diameter max (metric) 90.0mm
    Bundle ∅ 16.0-90.0mm
    Bundle ∅ min. 16.0mm
    Length (L) 340mm
    Min.Tensile Strength 535N
    Weight/Unit 0.0052kg
    Width (W) 7.6mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    Customs Number 39269097
    GTIN-13 / EAN 5022660307720
    Packaging 1 - Height (m) 0.04m
    Packaging 1 - Length (m) 0.406m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00247m³
    Packaging 1 - Weight (kg) 0.52kg
    Packaging 1 - Width (m) 0.152m
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Qty 2500
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Weight (kg) 13.802kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 50000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 297.04kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
