Cable tie, 200.7x8.0mm, ∅1.5-50.8mm, beige, 1000pcs.
Art.-No. 111-02374 | PAT100L-PAEK-BGE |  Details

    Package size
    Add to watchlist
    Downloads Datasheet
    Colour Beige (BGE)
    Material Polyaryletherketone (PAEK)
    PART DESCRIPTION PAT100L-PAEK-BGE
    Pack Cont. 1000pcs.
    Package Content packed in bag
    Type PAT100L
    Bundle Diameter max (metric) 50.8mm
    Bundle ∅ 1.5-50.8mm
    Bundle ∅ min. 1.5mm
    Length (L) 200.7mm
    Min.Tensile Strength 445N
    Weight/Unit 1.566kg
    Width (W) 8.0mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V0
    Hazardous Goods No
    Operating Temperature -55 °C to +200 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    Customs Number 39269097
    GTIN-13 / EAN 4031026593708
    Packaging 1 - Height (m) 0.06m
    Packaging 1 - Length (m) 0.375m
    Packaging 1 - Qty 1000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00675m³
    Packaging 1 - Weight (kg) 1566.000001kg
    Packaging 1 - Width (m) 0.3m
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.517525m
    Packaging 3 - Qty 5000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0344m³
    Packaging 3 - Weight (kg) 7830.610005kg
    Packaging 3 - Width (m) 0.3175m
    Packaging 4 - Height (m) 1.194m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 100000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.146m³
    Packaging 4 - Weight (kg) 156633.2kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
