Cable tie inside serrated, 632x7.6mm, ∅5.0-184.0mm, black, 50pcs.
Art.-No. 111-12846 | T120XLM-PA612-BK |  Details

    Add to watchlist
    Downloads Datasheet e-Learning
    Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
    Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 612 (PA612)
    PART DESCRIPTION T120XLM-PA612-BK
    Pack Cont. 50pcs.
    Package Content packed in bag
    Product Group Cable Ties inside serrated
    Releasable Closure (Yes/No) No
    Type T120XLM
    Variant Inside Serrated
    Bundle Diameter max (metric) 184.0mm
    Bundle ∅ 5.0-184.0mm
    Bundle ∅ min. 5.0mm
    Cable Tie Head Length (metric) 10.0mm
    Cable Tie Head Width (metric) 13.0mm
    Height (H) 7.8mm
    Length (L) 632mm
    Min.Tensile Strength 535N
    Strap Width max. (G) 0.51"
    Thickness (T) 1.9mm
    Width (W) 7.6mm
    CE Certification No
    CSA Certified No
    Halogen-free Yes
    Operating Temperature -40 °C to +90 °C
    ROHS compliant Yes
    Specifications
    Country of Origin US
    GTIN-13 / EAN 4031026714424
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
