For hard, smooth surface applications, we recommend the use of our LFPC protective channels.

Stainless steel cable tie, ball bearing lock, 362x4.6mm, ∅12-102mm, metal, 100pcs.
Art.-No. 111-01939 | MBT14SS-SS304-ML |  Details

Stainless steel cable ties, uncoated, MBT_SS, MBT_HS.

    • Cable ties MBT, made from stainless steel 304
    • Non-releasable locking feature
    • Corrosion resistant
    • Weather resistant
    • Outstanding chemical resistance
    • High temperature resistant
    • Non-burning
    Show more
    Add to watchlist
    Downloads Datasheet
    Application Metal ties are ideal for all applications that require high strength, reliability and fire resistance. The MBT range of stainless steel cable ties can be used in chemical industries and on oil platforms as well as in mass transit, shipbuilding and mining industries. MBT ties are also suitable for machine building, construction and in the outside area of radio technology. Additionally MBT ties are ideal for securing lighting in theatres and exhibition halls.
    Colour Metal (ML)
    Identification Plate Position none
    Internet Customer Notice For hard, smooth surface applications, we recommend the use of our LFPC protective channels.
    Key product features vibration absorbing
    Material Stainless Steel (SS304)
    PART DESCRIPTION MBT14SS-SS304-ML
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family MBT-Series, stainless steel 304
    Product Group Cable ties with ball-lock
    Releasable Closure (Yes/No) No
    Tie Closure ball bearing lock
    Type MBT14SS
    Variant Not Serrated
    Bundle Diameter max (metric) 102mm
    Bundle ∅ 12-102mm
    Bundle ∅ min. 12mm
    Length (L) 362mm
    Min.Tensile Strength 900N
    Thickness (T) 0.27mm
    Width (W) 4.6mm
    Limited Fire Hazard Yes
    Operating Temperature -80 °C to +538 °C
    ROHS compliant Yes
    Specifications
    Specifications ANSI/UL 1565, ANSI/UL 62275, EN 62275
    UL OCD link Link
    UL-File Number E193818
    Country of Origin CN
    GTIN-13 / EAN 4031026547732
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
