Fixing tie for hole (round), ∅1.6-30mm, grey, 500pcs.
Art.-No. 157-00098 | OS160FT6HEX-PA66-GY |  Details

Fir tree foot parts can be used for a variety of panel thicknesses.

    • Cable tie head always situated in defined position
    • Easy to assemble without the need for a tool
    • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
    • Fir tree foot part can be used for a variety of panel thicknesses
    • Suitable for use within threaded holes
    Show more
    Add to watchlist
    Downloads Datasheet
    Application Primarily designed for fixing cable harnesses in the automotive industry, their simplicity and ease of use has resulted in these parts being used in other industries, for example aviation, switch gear manufacturer, white goods manufacturer.
    Colour Grey (GY)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION OS160FT6HEX-PA66-GY
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family Fir tree parts FT6
    Product Group 1-piece fixing ties with fir tree, with disc, for round holes
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type OS160FT6HEX
    Bundle Diameter max (metric) 30mm
    Bundle ∅ 1.6-30mm
    Bundle ∅ min. 1.6mm
    Disc ∅ 16.0mm
    Length (L) 170.0mm
    Min.Tensile Strength 200N
    Thickness (T) 1.4mm
    Width (W) 5.3mm
    for Hole ∅ (FH) 6.35 mm
    for Panel Thickness min - max 0.7 - 5 mm
    ROHS compliant Yes
    Specifications
    Country of Origin SG
    GTIN-13 / EAN 4031026426549
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
