Fixing tie for hole (round), inside serrated, ∅1.5-50.8mm, beige, 2000pcs.
Art.-No. 156-04141 | PAT100RSDFT6.5SET-PAEK-BGE |  Details

    Add to watchlist
    Downloads Datasheet
    Colour Beige (BGE), Beige (BGE)
    Fixation Method Fir Tree
    Identification Plate Position none
    Material Polyaryletherketone (PAEK)
    PART DESCRIPTION PAT100RSDFT6.5SET-PAEK-BGE
    Pack Cont. 2000pcs.
    Package Content packed in carton
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type PAT100RSDFT6.5SET
    Variant Inside Serrated
    Bundle Diameter max (metric) 50.8mm
    Bundle ∅ 1.5-50.8mm
    Bundle ∅ min. 1.5mm
    Disc ∅ 19.7mm
    Height (H) 22.1mm
    Length (L) 150.5mm
    Min.Tensile Strength 445N
    Panel Thickness max. 0.6 - 6.75mm
    Thickness (T) 1.5mm
    Width (W) 4.0mm
    for Hole ∅ (FH) 6.1 - 6.7 mm, M8 Threaded
    for Panel Thickness min - max 0.6 - 6.8 mm
    for Panel Thickness min - max 0 - 0.3 "
    CE Certification No
    CSA Certified No
    Operating Temperature -55 °C to +200 °C
    ROHS compliant Yes
    Specifications
    Country of Origin US
    GTIN-13 / EAN 4031026675343
    Packaging 1 - Qty 2000
    Packaging 1 - Type carton
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121702
