Fixing tie with pipe/tube holder, inside serrated, ∅18.0mm, black, 3000pcs.
Art.-No. 156-00417 | T18ROC15-18CBTO-SD-SET-PA66HS/PA66HIRHS-BK |  Details

Pipe Clip CBTO, twistable 90°.

    This product is not available anymore.
    Add to watchlist
    Downloads
    Application Tool MK3PNSP2, MK3SP, MK20, EVO7i
    Colour Black (BK)
    Content 3000 T18R + 3000 OC15-18CBTO
    Fixation Method Omega Clip
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T18ROC15-18CBTO-SD-SET-PA66HS/PA66HIRHS-BK
    Pack Cont. 3000pcs.
    Package Content packed in box
    Product Group 2-Piece Fixing Ties with Pipe Clip
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T18ROC15-18CBTO-SD-SET
    Variant Inside Serrated
    Attach to Ø 15.0 - 18.0 mm
    Bundle Diameter max (metric) 18.0mm
    Bundle ∅ 18.0mm
    Length (L) 100.0mm
    ROHS compliant Yes
    Specifications
    Country of Origin DE
    GTIN-13 / EAN 4031026292977
    Packaging 1 - Height (m) 0.200m
    Packaging 1 - Length (m) 0.460m
    Packaging 1 - Qty 3000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.04784m³
    Packaging 1 - Weight (kg) 0.0020kg
    Packaging 1 - Width (m) 0.520m
    Packaging 2 - Height (m) 0.37m
    Packaging 2 - Length (m) 0.41m
    Packaging 2 - Qty 3000
    Packaging 2 - Type carton
    Packaging 2 - Volume (m³) 0.0485m³
    Packaging 2 - Weight (kg) 11.20kg
    Packaging 2 - Width (m) 0.32m
    Packaging 4 - Height (m) 1.08m
    Packaging 4 - Length (m) 1.16m
    Packaging 4 - Qty 60000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 0.952m³
    Packaging 4 - Weight (kg) 230.0kg
    Packaging 4 - Width (m) 0.76m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121731
