Fixing tie for stud, ∅1.5-50.0mm, black, 2000pc.
Art.-No. 156-01571 | T50R0SBL6UM90SET-PA66HIRHSUV/POM-BK Details

Cable Tie Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Colour Black (BK)
Fixation Method Stud Mount
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Polyacetal (POM)
PART DESCRIPTION T50R0SBL6UM90SET-PA66HIRHSUV/POM-BK
Pack Cont. 2000pc.
Package Content packed in bag
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50R0SBL6UM90SET
Bundle Diameter max (metric) 50.0mm
Bundle ∅ 1.5-50.0mm
Bundle ∅ min. 1.5mm
Height (H) 25.0mm
Length (L) 17.02mm
Min.Tensile Strength 225N
Stud ∅ 0.24"
Stud ∅ 6.0 mm
Weight/Unit 0.003356kg
Width (W) 11.72mm
for Hole ∅ (FH) M6 x 1
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +105 °C, -30 °C to +90 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised Yes
Country of Origin US
Customs Number 39269097
GTIN-13 / EAN 4031026543314
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.20955m
Packaging 3 - Length (m) 0.517525m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0344
Packaging 3 - Weight (kg) 7.322kg
Packaging 3 - Width (m) 0.3175m
Packaging 4 - Height (m) 1.194m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 40000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.146
Packaging 4 - Weight (kg) 167.44kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121731
