15/03/2025

Fixing tie for connector/for cable bundles, inside serrated, ⌀2.0-45.0mm, black, 5000pcs.
Art.-No. 156-03249 | T50RCC11M-SET-PA66HIRHS-BK

Copied
  • Easy to assemble without a need for a tool
  • Preassembled cable tie with connector clip
  • Connector can be removed without damage
  • Rattle-free mounting
Application These two piece fixing ties with connector clips have been designed for electronic cables and cable sets used in the automotve industry. The connector are pushed onto the connector clip and hold firmly in place.
Cable Tie Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Colour Black (BK)
Fixation Method Connector Clip
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T50RCC11M-SET-PA66HIRHS-BK
Pack Cont. 5000pcs.
Package Content packed in bag
Product Family Connector clip family
Product Group 2-piece fixing tie with connector clip
Releasable Closure (Yes/No) No
Short Description 2-piece part, Connector clip adapter with bundling bar and cable tie, outside serrated,⌀2-45mm (unassembled)
Tie Closure plastic pawl
Type T50RCC11M-SET
Type of connection USCAR11
Variant 11 mm USCAR Connector Clip
Bundle ⌀ 2.0-45.0mm
Bundle ⌀ max. 45.0mm
Bundle ⌀ min. 2.0mm
Height (H) 10.1mm
Length (L) 202mm
Min.Tensile Strength 225N
Weight/Unit 0.002239kg
Width (W) 24.9mm
ELV compliant (Article 4 - 2) YES
Halogen-free Yes
Hazardous Goods No
ROHS compliant Yes
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026732534
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 5000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 12.157kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.204m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 100000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.156
Packaging 4 - Weight (kg) 264.14kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
