28/11/2024

Fixing tie for hole (oval), outside serrated, ∅2.0-50.0mm, grey, 2000Carton
Art.-No. 133-02810 | T50SOSFT7X12-PA66HIRHS-GY Details

  • Cable tie head always situated in defined position
  • Easy to assemble without the need for a tool
  • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
  • Fir tree foot part can be used for a variety of panel thicknesses
  • Suitable for use within threaded holes
  • Versions for oval holes feature anti-twist protection
Show more
Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
Colour Grey (GY)
Fixation Method Fir tree for round holes
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T50SOSFT7X12-PA66HIRHS-GY
Pack Cont. 2000Carton
Package Content packed in carton
Product Family for oval holes
Product Group 1-piece fixing ties with fir tree, with disc
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50SOSFT7X12
Bundle Diameter max (metric) 50.0mm
Bundle ∅ 2.0-50.0mm
Bundle ∅ min. 2.0mm
Disc ∅ 16.0mm
Fixing Hole Shape Oval
Height (H) 14.8mm
Length (L) 157.0mm
Min.Tensile Strength 222N
Panel Thickness max. 0.8 - 14.5mm
Thickness (T) 1.3mm
Weight/Unit 0.01kg
Width (W) 4.8mm
for Hole ∅ (FH) 7.0 x 12.0 mm
for Panel Thickness min - max 0.8 - 14.5 mm
for Panel Thickness min - max 0 - 0.6 "
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
Country of Origin MX
Customs Number 39269097
GTIN-13 / EAN 4031026580852
Packaging 3 - Height (m) 0.35242499999999995m
Packaging 3 - Length (m) 0.5715m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0703
Packaging 3 - Weight (kg) 20.73kg
Packaging 3 - Width (m) 0.34925m
Packaging 4 - Height (m) 1.2m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 24000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.152
Packaging 4 - Weight (kg) 269.76kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
